3-Axis Hybrid Laser Marker Wide area MD-X2520A

MD-X2520A - 3-Axis Hybrid Laser Marker Wide area

*Please note that accessories depicted in the image are for illustrative purposes only and may not be included with the product.

Data Sheet (PDF)

Manuals

CAD Data

360°view (3D PDF)

Software

  • CE Marking
  • CSA

Specifications

Model

MD-X2520A

Type

Marking unit (controller + head) 25 W Wide area

Console (sold separately)

MB-PH1*1 (Marking Builder Plus, Marking Diagnostic Tool)

Handy console

MC-P1

3D function add-in (sold separately)

MD-AD-3D

XY tracking add-in (sold separately)

MD-AD-XYT

Z tracking add-in (sold separately)

MD-AD-ZT

2D code reader add-in (sold separately)

MD-AD-2DR/MD-AD-2DRA

Marking method

XYZ 3-Axis simultaneous scanning method

Marking laser

Type

YVO4 laser, Class 4 Laser Product (IEC/EN60825-1, JIS C6802, FDA(CDRH) Part 1040.10) *2

Wavelength

1064 nm

Output

25 W

Q-switch frequency

CW (continuous wave), 1 to 400 kHz

Distance laser

Semiconductor laser Wavelength: 683 nm
Output: 5.0 mW
Class 3R laser product
(IEC60825-1, JIS6802, FDA (CDRH) Part1040.10) *2

Guide laser/working distance pointer

Semiconductor laser, wavelength: 655 nm
output: 1.0 mW
Class 2 Laser Product
(IEC60825-1, JIS6802, FDA(CDRH) Part 1040.10) *2

Marking area

330 × 330 × 42 mm

Standard working distance (±variable width)

300 mm (±21 mm)

Marking resolution

5 μm

Scan speed

Max. 8000 mm/s

Character type

Font

KEYENCE original font (numbers, letters, katakana, hiragana, kanji), user font, TrueType font, OpenType font *3

Barcode

CODE39/ITF/2of5/NW7 (CODABAR)/JAN/CODE128/EAN/UPC-A/UPC-E/CODE93

2D code

QR code, micro QR code, DataMatrix (ECC200/GS1 DataMatrix)

GS1 DataBar

GS1 DataBar/GS1 DataBar CC-A/GS1 DataBar Stacked/GS1 DataBar Stacked CC-A/
GS1 DataBar Limited/GS1 DataBar Limited CC-A/GS1 DataBar Truncated/GS1 DataBar Truncated CC-A

Logo image

Custom character font and logo (CAD) data, BMP/JPEG/PNG/TIFF

Marking conditions

Workpiece style

Stationary marking, Moving marking (constant, encoder)

Character size (height/width)

0.1 to 330 mm

No. of registered jobs

2000 max.

No. of setting blocks

256

Input/output

Terminal block I/O, MIL connector I/O, laser safety module control I/O *4

Interface

RS-232C/USB2.0/Ethernet (100BASE-TX/10BASE-T) *5

Marking head installation direction

All directions

Marking head cable length

4.3 ±0.1 m

Cooling method

Forced air cooling

Applicable regulations

EU directives (EMC Directive, Low Voltage Directive, RoHS Directive)/EN standards (EN61010-1, EN60825-1, EN62471, EN55011, EN61000-6-2, EN50581)/
CSA standards and UL standards (CAN/CSA C22.2 No.61010-1, UL61010-1)/North American regulations (FCC Part 15B, ICES-001 Class A)/China RoHS/UKCA

Rated voltage and power consumption

100 to 240 VAC ±10% 50/60 Hz, 850 VA max.

Environmental resistance

Enclosure rating

IP64 (marking head)

Ambient temperature for transport/storage

-10 to 60°C (no freezing)

Ambient humidity for transport/storage

30 to 85% (no condensation)

Ambient temperature

0 to 40°C

Relative humidity

30 to 85% (no condensation)

Overvoltage category

II

Pollution degree

2

Weight

Controller: 23.0 kg
Marking head: 13.8 kg
Console: 2.0 kg

*1 Supported operating systems: Windows 11 / Windows 10 Languages:English/Japanese/Simplified Chinese/Traditional Chinese/German/Korean/French/Spanish/Thai/Italian.
*2 The laser classification for FDA (CDRH) is implemented based on IEC60825-1 in accordance with the requirements of Laser Notice.
*3 The only TrueType and OpenType fonts supported are those fonts whose "Font embeddability" property is set to "Installable" or "Editable." This property can be viewed from the Properties dialogue boxes of the fonts shown on the [Fonts] screen in [Control Panel].
*4 Only when the laser safety module (MD-C2A/MD-C2B) is installed.
*5 There are two USB ports: a Type A connector for connecting USB memory devices or a USB mouse and a Type B connector that is the dedicated port for Marking Builder Plus (ActiveX). The Ethernet port supports communication with Marking Builder Plus (ActiveX), TCP/IP communication, EtherNet/IP™ and PROFINET.
