Specifications

Head(VR-3200/VR-3100/VR-3050), Controller VR-3000K, Control PC and Monitor (optional)

VR Head / Controller

Model Controller VR-3000K
Head VR-3200 VR-3100 VR-3050
  Wide-field mode High magnification mode Wide-field mode High magnification mode Wide-field mode
Magnification on a 15" monitor 12× 25× 38× 50× 40× 80× 120× 160× 12× 25× 38× 50× 40× 80× 120× 160× 12× 25× 38× 50×
Field-of-view Horizontal (H):
mm		 24.0 12.0 8.0 6.0 7.6 3.8 2.5 1.9 24.0 12.0 8.0 6.0 7.6 3.8 2.5 1.9 24.0 12.0 8.0 6.0
Vertical (V):
mm		 18.0 9.0 6.0 4.5 5.7 2.9 1.9 1.4 18.0 9.0 6.0 4.5 5.7 2.9 1.9 1.4 18.0 9.0 6.0 4.5
Zoom 1x to 4x
Measurable height*1 10mm
(±5mm)		 1mm
(±0.5mm)		 10mm
(±5mm)		 1mm
(±0.5mm)		 10mm
(±5mm)
Reference scale*2 0.1μm 0.5μm
Working distance 75mm
Image receiving element 4 megapixel monochrome CMOS
Transmitter lens Double telecentric lens x2
Receiver lens Double telecentric lens
Light sources Observation light source LED ring light (red, green, blue) LED ring light (white)
Measurement light source White LED
  • *1Low magnification ±5 mm and high magnification ±0.5 mm around the focal point position.
  • *2Measurement resolution on the Z-axis (height).
